BLUETTI RV5 RV Power Hub - 5,000W AC, 1,620W DC
BLUETTI RV5 RV Power Hub - 5,000W AC, 1,620W DC
Couldn't load pickup availability
Product Overview
Important Battery Notice: This listing includes the BLUETTI RV5 Power Hub only. A battery is not included, and the RV5 is not a standalone portable power station.
The BLUETTI RV5 is an installed RV power hub designed to combine AC power conversion, battery charging, solar charging, vehicle charging, DC distribution, monitoring connections, and system protection functions in one unit.
It provides up to 5,000W of 120V AC output and supports 12V or 24V DC distribution. A compatible battery system is required for stored-energy operation. The BLUETTI B4810 battery is sold separately and is included in selected RV5 bundle and kit listings.
Key Features
- 5,000W rated 120V AC output
- 42A rated AC output current
- 12V or 24V DC distribution output
- Up to 1,360W DC output at 12V
- Up to 1,620W DC output at 24V
- Up to 1,800W solar input
- Vehicle charging input up to 600W with a 12V system or 1,200W with a 24V system
- Supports shore-power, solar, vehicle, compatible generator, and optional EV charging inputs
- UPS switchover time of 20 milliseconds or less
- Maximum combined system load of 6,000W, depending on battery type and quantity
Best For / Intended Use
- RV and camper electrical-system upgrades
- Van conversions and custom mobile-power installations
- Systems requiring integrated AC and DC power management
- Customers building a customized RV5 system with separately selected batteries and distribution components
- Installations using shore power, solar charging, or vehicle-alternator charging
What Is Included
- BLUETTI RV5 Power Hub × 1
- M8 wood screws × 8
- Anchors × 8
- Drilling template × 1
- User manual × 1
Not Included: Battery, Epanel, Epad, solar panels, EV charging cable, distribution wiring packages, and installation labor are not included unless specifically identified in a separate bundle or kit listing.
Technical Specifications
| Model | RV5 |
|---|---|
| Product Type | Installed RV power hub and inverter-charger |
| Standard AC Input Voltage | 120V |
| EV Input Voltage | 208V |
| Maximum Charging Power | 5,000W, limited by the connected battery system |
| Rated AC Output Voltage | 120V |
| Rated AC Output Current | 42A |
| Rated AC Output Power | 5,000W |
| UPS Switchover Time | 20 milliseconds or less |
| Maximum Solar Input | 1,800W |
| Solar Input Voltage | 12V–50V |
| Maximum Solar Input Current | 50A |
| Vehicle Charging Input | 600W with a 12V system or 1,200W with a 24V system |
| Vehicle Input Voltage | 12V–14.4V with a 12V battery or 24V–28.8V with a 24V battery |
| Maximum Vehicle Input Current | 50A |
| DC Output Voltage | 12V or 24V |
| DC Output Current | 100A at 12V or 60A at 24V |
| Rated DC Output Power | 1,360W at 12V or 1,620W at 24V |
| Maximum Combined Load | 6,000W, depending on battery type and quantity |
| Maximum Combined AC and DC Input | 6,000W |
| Dimensions | 17.72 × 19.69 × 6.30 inches (450 × 500 × 159.9mm) |
| Weight | Approximately 30.86 lb (14kg) |
| Operating Temperature | -4°F to 131°F (-20°C to 55°C) |
| Maximum Operating Humidity | 95% |
| Manufacturer-Listed Certification | UL 458 |
Setup and Compatibility
The RV5 Power Hub does not contain a battery. A compatible battery system is required for stored-energy operation. The BLUETTI B4810 is the matched 51.2V battery used in BLUETTI RV5 bundle and kit configurations.
The RV5 Power Hub listing does not include the Epanel smart distribution panel or Epad control screen. Customers who need those components should select the appropriate complete RV5 kit.
Before ordering, confirm the required battery capacity, connection cables, communication cables, AC and DC distribution equipment, cable lengths, breakers, fuses, grounding components, mounting locations, and ventilation requirements.
Installation requires correctly rated wiring, overcurrent protection, grounding, secure mounting, and integration with the RV’s existing AC and DC electrical systems. Follow the current BLUETTI instructions and all applicable electrical requirements.
Use a qualified installer when required or when the installer is not experienced with high-current AC and DC RV systems.
Shipping and Delivery
This item ships directly from our fulfillment partner or manufacturer.
Freight charges are calculated at checkout.
Estimated Delivery:
- Processing: 1–2 business days
- Delivery: 5–10 business days depending on location
Oversized or high-value items may require additional handling or scheduled delivery.
Tracking information will be provided once your order ships.
See our Shipping Policy for full details.
Warranty and Returns
Warranty service and returns are subject to the applicable manufacturer terms and RoboSmartDepot's current Warranty and Refund policies. Review those policies before ordering.
Safety, Compliance, and Important Notes
- This listing does not include a battery.
- Disconnect all power sources before installation, wiring, inspection, or maintenance.
- Use correctly rated cables, terminals, fuses, breakers, grounding, and distribution equipment.
- Install the RV5 in a dry, protected, properly ventilated location.
- Do not block the cooling fans or ventilation openings.
- Do not use the RV5, wiring, cables, or connected components if they appear damaged.
- Follow the current BLUETTI RV5 installation and operating instructions.
